go-doom / engine

Pure-Go DOOM (id Tech 1, 1993) engine for bare-metal TamaGo + UEFI under the cloud-boot loader. Sibling of the go-quake1 family (go-quake1 / go-quake2 / go-quake3 — the id Tech 1/2/3 ports).

Fork origin

This repository is a fork of AndreRenaud/gore at commit 7dc6c65493b8a29e0b93dd00dac21a2f10a0068a (2026-05-11).

gore itself is a Go transpilation of doomgeneric performed with modernc.org/ccgo/v4 and then hand-cleaned. The engine has no CGO dependency, only standard library, and exposes its host bindings through a small DoomFrontend interface -- exactly the shape we need to wire DOOM into cloud-boot's virtio device tree.

The upstream README.md is preserved as README.upstream.md.

Why this fork exists

cloud-boot is building an OS-agnostic OCI boot architecture on top of TamaGo + UEFI. To showcase Phase 3 we want to run classic DOOM as the "OS payload", with rendering, sound, and input wired straight to virtio devices instead of SDL / X11 / a kernel.

This fork therefore adds:

• backend/tamago/ -- a new DoomFrontend implementation that drives cloud-boot's virtio-gpu, virtio-sound, and virtio-input drivers (currently stub interfaces; real wiring lands once go-virtio/sound and go-virtio/input ship in their sibling sprints).
• internal/embedwad/ -- an io/fs.FS shim that serves a WAD blob from memory, so the engine can load the IWAD without a real filesystem.

The upstream gore engine (doom.go, ~990 KB of transpiled code, plus doom_test.go) and its existing terminal / web / Ebitengine / SDL examples are kept verbatim, so we can rebase against upstream cleanly.

License boundary

• The DOOM engine (doom.go, doom_test.go, LICENSE) inherits GPL-2.0-only from doomgeneric / gore. All cloud-boot additions in this repository (backend/tamago, internal/embedwad) are released under the same license, by necessity (linking + derived work).
• The rest of the cloud-boot stack is BSD-3-Clause and is not affected: cloud-boot's bootloader, runtime, and host components do not import this package. The integration happens via a thin separate "livedoom" boot artifact whose only job is to call godoom.Run. That artifact will itself be GPL-2.0, isolated to a single directory in the cloud-boot/tamago-uefi tree.

Layout

.
|-- doom.go                     # upstream gore engine (transpiled DOOM)
|-- doom_test.go                # upstream gore reference-frame tests
|-- example/                    # upstream gore examples (termdoom, web, ...)
|-- backend/
|   `-- tamago/                 # NEW: DoomFrontend over virtio-gpu/sound/input
|-- internal/
|   `-- embedwad/               # NEW: io/fs.FS shim over an in-memory WAD
|-- PORT.md                     # Adaptation plan (read this)
`-- README.md

Status

Aspect	Status
Pure Go (CGO=0)	yes (engine + all new code)
Builds on Go 1.26.4	yes (lib + tamago backend + pure-Go examples)
Cross-compiles linux/amd64	yes (CGO=0)
Cross-compiles linux/arm64	yes (CGO=0)
Runs shareware DOOM1.WAD	yes (engine ticks; verified via TestMenus harness)
TamaGo backend wired	scaffold only; real drivers land in follow-up sprint
Music (MUS -> MIDI)	out of scope for sprint 1
Multiplayer	out of scope

Quick smoke test (host)

# 1. fetch the shareware IWAD (free re-release):
curl -sSL -o doom1.wad https://distro.ibiblio.org/slitaz/sources/packages/d/doom1.wad

# 2. terminal renderer (pure Go):
CGO_ENABLED=0 go run ./example/termdoom -iwad doom1.wad

cloud-boot integration points

The TamaGo backend in backend/tamago/ consumes three driver interfaces declared in that package:

Frontend method	Backend interface	Driver repo (sibling)
DrawFrame(*image.RGBA)	GPU.Flip	github.com/go-virtio/gpu
CacheSound / PlaySound	Sound.Cache/Play	github.com/go-virtio/sound
GetEvent(*DoomEvent)	Input.Poll	github.com/go-virtio/input

The WAD is delivered to the engine via gore.SetVirtualFileSystem(fs.FS) using the internal/embedwad helper, whose backing bytes can come from either (a) a go:embed blob in the cloud-boot "livedoom" boot artifact, or (b) a runtime stream from a cloud-boot OCI artifact mount.

The actual wire-in (phase3_oci_doom_boot.go in cloud-boot/tamago-uefi) is a follow-up sprint and is intentionally NOT done here.

See PORT.md for the detailed adaptation plan.

How to verify the cloud-boot DOOM demo is operational (R-doom1g)

The provable test protocol lives in cloud-boot/docs/docs/architecture/doom-provable-protocol.md. Short version:

# Re-harvest the host oracle (byte-equal reproducible — proves
# engine + WAD + determinism hooks are intact):
cd go-doom/engine
GOWORK=off go run ./cmd/harvest-reference \
    -wad embedwad/doom1.wad \
    -seed 0 \
    -checkpoints 1,35,70,140,350,1050 \
    -out /tmp/fresh-oracle

# Compare against the committed oracle — every SHA must match.
diff <(cd oracle && sha256sum frame_tic*.ppm) \
     <(cd /tmp/fresh-oracle && sha256sum frame_tic*.ppm)

For the full guest-stack gate (boots the EFI probe in QEMU+EDK2 and compares virtio-gpu output against the guest oracle):

cd cloud-boot/tamago-uefi
task doomboot:efi:amd64
bash internal/livedoomboot/provable_test.sh amd64

The oracle/ directory is committed (~1.1 MiB of PPMs + manifest). The WAD itself is .gitignored (see embedwad/.gitignore). The determinism hooks live in seed.go (sibling of doom.go, never modifying the transpiled engine source).
